Type of receiver
|
6 channel GPS C/A-code receiver
|
|
Type of antenna
|
Remote powered (by GPSGEN1575/MP) antenna/converter unit
Length of cable up to 300 m (standard coaxial cable RG58)
Antenna circuit 1000 V DC insulated
|
|
Status info
|
Two LEDs (Lock und Fail) and one relay output showing status of the clock
|
|
Input signal
|
Antenna input for Meinberg GPS antenna with IF-technology (35,42 MHz)
|
|
Pulse outputs
|
High-active pulse per second (PPS), TTL-level, pulse width 1 msec, accuracy better than ± 250nsec
|
|
Interface
|
Two independent serial RS232-interfaces, menu configurable
|
|
Data format of interfaces
|
Baudrate: 300, 600, 1200, 2400, 4800, 9600, 19200 Baud data format: 7N2, 7E1, 7E2, 8E1, 8N1, 8N2 Time telegram: Meinberg Standard-Telegram, SAT, Uni Erlangen (NTP), SPA, NMEA0183 (RMC)
|
|
Output signal
|
4 x 1575,42 MHz (GPS L1C/A-code) for GPS receivers without IF-technology
3 x 35,42 MHz (Meinberg IF) for Meinberg GPS receivers
|
|
Power Supply Unit
|
Standard PSU:
85 ... 264VAC, 47 ... 63Hz
Several other power supply units (even for DC power supply) are available upon request.
|
|
Form Factor
|
19'' aluminium case (1U) Schroff Multipac
|
|
Protection
|
IP20
|
|
Ambient temperature
|
0 ... 50°C / 32 ... 122°F
|
|
Humidity
|
Max. 85%
|
|
Warranty
|
Three-Year Warranty
|
|
RoHS-Status of the product
|
This product is fully RoHS compliant
|
|
WEEE status of the product
|
This product is handled as a B2B category product. In order to secure a WEEE compliant waste disposal it has to be returned to the manufacturer. Any transportation expenses for returning this product (at its end of life) have to be incurred by the end user, whereas Meinberg will bear the costs for the waste disposal itself.
|
